factory High Voltage Portable Grounding Rod
Price: |
19.0~39.0 USD |
Payment Terms: |
T/T, |
Place of Origin: |
Hebei, China (Mainland) |
Product Detail
Means of Transport:
Land,
Packing:
carton
Production Capacity:
10000/year
Delivery Date:
7days
Technical:
Type Suitable voltage(kV) Rated short-circuit current(kA/1S) Size of earth wire(mm2) Insulating length of rod(rope)(mm)
factory High Voltage Portable Grounding Rod
Technical:
Type | Suitable voltage(kV) | Rated short-circuit current(kA/1S) | Size of earth wire(mm2) | Insulating length of rod(rope)(mm) |
JDB-1 | 0.5 | 4.2 | 16-25 | ≥100 |
JDB-2 | 0.5-110 | 6.5-13 | 25-50 | ≥300-1300 |
JDB-3 | 10-220 | 6.5-13 | 25-50 | ≥700-2000 |
JDB-4 | 10-500 | 6.5-13 | 25-50 | ≥900-3700 |
JDB-5 | 110-220 | 6.5-13 | 25-50 | ≥1300-2100 |
JDB-6 | 110-500 | 6.5-13 | 25-50 | ≥1300-3700 |
JDB-7 | 10-200 | 6.5-13 | 25-50 | ≥700-1300 |
JDB-8 | 10-35 | 6.5-13 | 25-50 | ≥300-2100 |
JDB-9 | 220-500 | 6.5-13 | 25-50 | ≥700-900 |
This earthing stick is designed for using to protect workers from high voltaged electric shock on steel tower.
Specification
1.Flexible lead(Copper ground wire):3 rolls with clamp 2 type.
2.Fiber glass pole :1~3 pole with handle.
Portable electrical earth rod/Grounding rod,
Earth rods set with wire and earth pin.
Suitable for making power failed equipments or temporary short-circuited lines grounded, preventing unexpected power to intrude in and do damage to personnel and equipments.
factory High Voltage Portable
Grounding Rod
